Special Reminder:
The indicated global retail price only for your reference. Contact with us to get more discount and its current inventory quantity of us which located in your country.
Feature
Parameter Table
| Items | Condition | 300AH |
| Nominal Capacity | Standard charge/discharge | 300.0Ah |
| Nominal Voltage | Average | 12.8V |
| Internal Impedance | at 1KHz after50% charge | ≤10mΩ |
| Standard Charging | Constant current | 60A |
| Constant voltage | 14.6V | |
| End current（Cut off） | 2A | |
| Charging Voltage | / | 14.6V |
| Max. Continuous Charge | 25±3℃ | 100.0A |
| Standard Discharging | Constant current | 75A |
| End voltage（Cut off） | 10V | |
| Max Continuous Discharge | 25±3℃ | 200A |
| Cycle Life（Optional) | 0.2C, 80% DOD, 25±3℃ 25±3℃ | 3000 times |
| Operating Temperature | Charge | 0℃~ 60℃ |
| Discharge | -20℃~ 60℃ | |
| Storage Temperature | 1 months | -20℃~ 45℃ |
| 3 months | -20℃~ 35℃ | |
| 6 months | -20℃~ 25℃ | |
| Consumption | Low power consumption mode | ≤100μA |
| Over charge Protection |
Over charge detection voltage | 3.75V |
| Over charge release voltage | 3.38V | |
| Over discharge protection |
Over discharge detection voltage | 2.7V |
| Over discharge release voltage | 2.95V | |
| Over current protection |
Charging overcurrent detection time | 110A (1S) |
| Discharging overcurrent detection time(1) | 220A (1S) | |
| Discharging overcurrent detection time(2) | ≥300A(100ms) | |
| Temp. Protection | Detection temperature | 65±2℃ |
Certifications
