Feature
| Product Specifications | Contents of Technical Instructions (MDDC) |
| rated power | 80kw |
| number of guns | single and double guns |
| Single gun output maximum current | 200A |
| Stake line length | Standard 5 meters (optional) |
| Constant power output voltage range | DC400~750V (Optional) |
| Dimensions | 1700×750×400mm(W×H×D) |
| Display method | 7-inch touch display |
| Host computer communication | Ethernet/4G (Speed Dating) |
| charging mode | Automatic charging,by time,by power,by amount,etc. |
| Start method | Swipe IC card,scan QRcode (APP,WeChat,etc.) |
| Protective function | Short circuit over temperature,over current,leakage,over and under voltage,etc. |
| charging method | Full power charging ABequalizing charging,wheel charging |
| Network background | Support cloud platforms such as State Grid,Cloud Quick Charge,Xiaoju,Wejingyun,etc. |
| Input voltage | AC380V±20% |
| input frequency | 50Hz±10%Hz |
| Output voltage range | DC150-750V adjustable |
| Output voltage eror | s+0.5% |
| Output current error | ≤±1% |
| Voltage regulation accuracy | s+0.5% |
| Steady flow accuracy | S+1% |
| Harmonic content | ≤±5% |
| power factor | ≥0.99 |
| effciency | ≥95% |
| Electric energy metering | Grade 1.0 meets GB standard |
| Insulation resistance | ≥100M |
| noise | ≤60dB |
| Protection class | lp54 |
| Use environment | outdoor or indoor |
| cooling method | air cooling |
| Operating temperature | -20℃~+50℃ |
| Storage temperature | -40℃~+70℃ |
| Relative humidity | 5%~95% |
| Altitude | ≤2000m |
| Installation method | Floor installation |
